Bromic
Bromic Platinum Marine
BH3622002
$5,786.00
BUILD YOUR HEATING SOLUTION
Choose your heater, then complete your setup below.
Platinum Marine brings the glass-front electric-heater form to a 316 stainless-steel configuration for land-based coastal spaces. Match the exact power, finish and supply to the installation.
Specifications & resources
| Model | BH3622002 |
|---|---|
| Heater power | 4500 W |
| Nominal supply | 240 V |
| Color | Black |
| Dimensions (W × H × D) | 1351 × 257 × 54 mm |
| Weight | 15 kg |
| Ingress protection | IP55 |
| Model | BH3622002 |
|---|---|
| Heater power | 4500 W |
| Nominal supply | 240 V |
| Color | Black |
| Dimensions (W × H × D) | 1351 × 257 × 54 mm |
| Weight | 15 kg |
| Ingress protection | IP55 |
| Model | BH0320016 |
|---|---|
| Heater power | 3400 W |
| Supply | 220–240 V AC |
| Color | Black |
| Dimensions (W × H × D) | 1275 × 182 × 54 mm |
| Weight | 10 kg |
| Finish | Brushed stainless steel 316 |
| Ingress protection | IPX5 |
| Model | BH0320015 |
|---|---|
| Heater power | 2300 W |
| Supply | 220–240 V AC |
| Color | Black |
| Dimensions (W × H × D) | 840 × 182 × 54 mm |
| Weight | 7.5 kg |
| Finish | Brushed stainless steel 316 |
| Ingress protection | IPX5 |
| Model | BH3622003 |
|---|---|
| Heater power | 4500 W |
| Nominal supply | 240 V |
| Color | White |
| Dimensions (W × H × D) | 1351 × 257 × 54 mm |
| Weight | 15 kg |
| Ingress protection | IP55 |
| Model | BH0320018 |
|---|---|
| Heater power | 3400 W |
| Supply | 220–240 V AC |
| Color | White |
| Dimensions (W × H × D) | 1275 × 182 × 54 mm |
| Weight | 10 kg |
| Finish | Brushed stainless steel 316 |
| Ingress protection | IPX5 |
| Model | BH0320017 |
|---|---|
| Heater power | 2300 W |
| Supply | 220–240 V AC |
| Color | White |
| Dimensions (W × H × D) | 840 × 182 × 54 mm |
| Weight | 7.5 kg |
| Finish | Brushed stainless steel 316 |
| Ingress protection | IPX5 |
| Model | BH3622006 |
|---|---|
| Heater power | 4500 W |
| Nominal supply | 208 V |
| Color | Black |
| Dimensions (W × H × D) | 1351 × 257 × 54 mm |
| Weight | 15 kg |
| Ingress protection | IP55 |
| Model | BH0320025 |
|---|---|
| Heater power | 3400 W |
| Supply | 208–208 V AC |
| Color | Black |
| Dimensions (W × H × D) | 1275 × 182 × 54 mm |
| Weight | 10 kg |
| Finish | Brushed stainless steel 316 |
| Ingress protection | IPX5 |
| Model | BH0320023 |
|---|---|
| Heater power | 2300 W |
| Supply | 208–208 V AC |
| Color | Black |
| Dimensions (W × H × D) | 840 × 182 × 54 mm |
| Weight | 7.5 kg |
| Finish | Brushed stainless steel 316 |
| Ingress protection | IPX5 |
| Model | BH3622007 |
|---|---|
| Heater power | 4500 W |
| Nominal supply | 208 V |
| Color | White |
| Dimensions (W × H × D) | 1351 × 257 × 54 mm |
| Weight | 15 kg |
| Ingress protection | IP55 |
| Model | BH0320026 |
|---|---|
| Heater power | 3400 W |
| Supply | 208–208 V AC |
| Color | White |
| Dimensions (W × H × D) | 1275 × 182 × 54 mm |
| Weight | 10 kg |
| Finish | Brushed stainless steel 316 |
| Ingress protection | IPX5 |
| Model | BH0320024 |
|---|---|
| Heater power | 2300 W |
| Supply | 208–208 V AC |
| Color | White |
| Dimensions (W × H × D) | 840 × 182 × 54 mm |
| Weight | 7.5 kg |
| Finish | Brushed stainless steel 316 |
| Ingress protection | IPX5 |
